| Du in | 40 |
| Dу out | 65 |
| - |
| Weight, kg] | - | 16 |
| with bellows | 17 |
| Center to ends. surface [mm] | Entrance a | 140 |
| Output b | 115 |
| Height (H4) [mm] | H max. standard | 512 |
| Bellows H max . | 550 |
| Body material: 0.6025 (Cast iron) |
| DIN flange | entrance | PN16 |
| Output | PN16 |
| Body material | B | D | E |
| [mm] | [mm] | [mm] |
| 0.6025 | 150 | 290 | 16 |
| Du in | 40 |
| Dу out | 65 |
| Body material: 0.6025 (Cast iron) |
| DIN flange | entrance | PN16 |
| Output | PN16 |
| Minimum install. pressure | p [bar] | 0.1 |
| Min. installed pressure standard bellows | p [bar] | 3 |
| Min. installed bellows pressure low. pressure | p [bar] | 1.11 |
| Maximum set pressure | p [bar] | 16 |
| Max. installed pressure from spec. spring | p [bar] | 16 |
| Temperature according to DIN EN | min. [0C] | -ten |
| Max. [0C] | +300 |
| Du in | 40 |
| Dу out | 65 |
| Set pressure [bar] | Throughput [kg / h] |
| 0.2 | 363 |
| 0.5 | 579 |
| 1 | 843 |
| 2 | 1343 |
| 3 | 1808 |
| 4 | 2254 |
| 5 | 2699 |
| 6 | 3142 |
| 7 | 3574 |
| 8 | 4014 |
| 9 | 4454 |
| 10 | 4893 |
| 12 | 5770 |
| 14 | 6629 |
| 16 | 7505 |
| 18 | 8382 |
| 20 | 9260 |
| 22 | 10111 |
| 24 | 10991 |
| 26 | 11873 |
| 28 | 12757 |
| 30 | 13644 |
| 32 | 14534 |
| 34 | 15384 |
| 36 | 16278 |
| 38 | 17175 |
| 40 | 18076 |
-
| Du in | 40 |
| Dу out | 65 |
| Set pressure [bar] | Throughput [m 3 / h] |
| 0.2 | 420 |
| 0.5 | 680 |
| 1 | 1004 |
| 2 | 1622 |
| 3 | 2209 |
| 4 | 2773 |
| 5 | 3337 |
| 6 | 3900 |
| 7 | 4464 |
| 8 | 5028 |
| 9 | 5592 |
| 10 | 6155 |
| 12 | 7283 |
| 14 | 8411 |
| 16 | 9538 |
| 18 | 10666 |
| 20 | 11793 |
| 22 | 12921 |
| 24 | 14048 |
| 26 | 15176 |
| 28 | 16304 |
| 30 | 17431 |
| 32 | 18559 |
| 34 | 19686 |
| 36 | 20814 |
| 38 | 21941 |
| 40 | 23069 |
| Du in | 40 |
| Dу out | 65 |
| Set pressure [bar] | Throughput [10 3 kg / h] |
| 0.1 | 11.0 |
| 0.2 | 13.5 |
| 0.5 | 19.1 |
| 1 | 25.8 |
| 2 | 36.5 |
| 3 | 44.7 |
| 4 | 51.6 |
| 5 | 57.7 |
| 6 | 63.2 |
| 7 | 68.3 |
| 8 | 73.0 |
| 9 | 77.4 |
| 10 | 81.6 |
| 12 | 89.4 |
| 14 | 96.6 |
| 16 | 103 |
| 18 | 110 |
| 20 | 115 |
| 22 | 121 |
| 24 | 126 |
| 26 | 132 |
| 28 | 137 |
| 30 | 141 |
| 32 | 146 |
| 34 | 151 |
| 36 | 155 |
| 38 | 159 |
| 40 | 163 |
